67 nano-layers of hold, from 10 microns thin.
Nanofilm is cast stretch film co-extruded in 67 nano-layers on a state of the art nano-layer extrusion line. Each layer is laid down through a precision nano-layer feedblock, and together they give the film far more robust characteristics than its thickness suggests: high holding force, consistent performance at speed, and stretch of up to 380%. Incredible performance despite its thickness, with less plastic on every load.
We have supplied Nanofilm since 2018, and we have pushed the technology further since. Standard Nanofilm covers everyday machine wrapping, and our special High Elongation range takes on the really challenging loads at very low thicknesses. We'll benchmark either against your current film, free, on your own pallets.
Request a demo or more information
Tell us a little about your operation and we’ll arrange a Nanofilm demo on your own pallets, or send you the information you need. Free, with no obligation.
We’ll only use your details to respond to your enquiry. See our privacy policy.
Prefer to talk? Call 01795 430 064.
The Nanofilm range.
Two families of film. Between them, every machine wrapped pallet in the warehouse is covered.
Standard Nanofilm
The everyday workhorse. Nano-layer strength at low micron for consistent, reliable machine wrapping. Less film on every pallet than conventional machine film, with the holding force to keep loads secure at full line speed.
Available now.
High Elongation Nanofilm
For the really challenging loads. Our special range that pushes nano-layer technology to its boundaries. The 10 micron grade stretches to 300% and the 12 micron grade to 350%, so one roll wraps further and grips harder on heavy, sharp or unstable pallets.
Available now.
Why 67 nano-layers changes the film.
A conventional cast film is extruded in a handful of layers. Nanofilm is co-extruded in 67, through a precision nano-layer feedblock that sequences each polymer exactly where it works hardest: cling and release skins for clean unwinding at speed, and core layers tuned for toughness and holding force. The layering gives the film far more robust characteristics than a conventional film of the same gauge, which is how a film as thin as 10 microns replaces far thicker conventional films. Strength from structure, not from thickness.
Why customers switch to Nanofilm
Film from just 10 microns thin
Dramatically less plastic on every pallet than thicker conventional films.
Up to 380% stretch
One roll wraps more pallets, with fewer roll changes and a lower cost per pallet.
67 nano-layer construction
Robust, consistent film characteristics engineered into the structure itself.
Nanofilm specialists since 2018
Stocking, benchmarking and pushing nano-layer films to their limits ever since.
Lower Plastic Packaging Tax bill
Less plastic per pallet means fewer taxable tonnes every quarter.
100% recyclable
Single polymer film that goes into the standard recycling stream.
The same pallet. Every film.
Seven films, one identical wrap: 15 rotations of the same 4.4 metre perimeter pallet, each film at its rated stretch. The only thing that changes is how much plastic each film needs to do the job.
| Film | Optimised stretch | Film used per pallet | Pallets per roll | Plastic vs 23 micron film |
|---|---|---|---|---|
| High Elongation Nanofilm, 10 micron | 300% | 76g | 196 | 62% less |
| High Elongation Nanofilm, 12 micron | 350% | 81g | 184 | 59% less |
| Standard Nanofilm, 12 micron | 250% | 104g | 143 | 48% less |
| Standard Nanofilm, 15 micron | 380% | 95g | 157 | 52% less |
| Conventional film, 17 micron | 250% | 147g | 101 | 26% less |
| Conventional film, 20 micron | 250% | 173g | 86 | 13% less |
| Conventional film, 23 micron | 250% | 199g | 75 | Baseline |
Calculated figures based on each film’s rated stretch: identical 16kg rolls (14.9kg of film), 15 rotations of a 4.4 metre perimeter pallet. Your results depend on your machine and load, which is exactly what the free benchmark measures.
Questions we get asked
Standard or High Elongation, which do I need?
What is nano-layer technology?
Is 10 microns really strong enough to hold a pallet?
Can I see the difference without a site visit?
How does Nanofilm cut my Plastic Packaging Tax bill?
How quickly can I get it?
Find your Nanofilm with a free benchmark.
Tell us your machine, your load and your current film, and we'll test the right Nanofilm against it on your own pallets and give you the numbers. Or send us your wrap details for a simulated comparison.
